No tools required to clean SPC

No tools required to clean SPC|HARMO Co.,Ltd

Compared to other crushers, SPC requires less time to clean because no tools are needed for cleaning.

img_hero_dummy@2x

Comparison object

Manufacturers Model Motor capacity
Harmo SPCII-1500(S)  1.5kw: 2 horsepower
A A 1.5kw: 2 horsepower
B B 1.5kw: 2 horsepower
C C 1.5kw: 2 horsepower

How to Test

  1. Sprues for 10 shots were manually feed into each crusher at 20 second intervals, and crushed material that fell into saucer under crusher blade was collected in a plastic bag.
  2. After that, crusher was disassembled and cleaned to ensure that no resin powder remained in contents, including shooter, coarse grinding blade, and crushing blade. The time from disassembly to cleaning and assembly was measured.

Result

Manufacturers Model Cleanup time Time Ratio
Harmo SPCII-1500(S) 595sec 100
A A 950sec 160
B B 630sec 106
C C 635sec 107

From above table, cleaning time of Harmo is the shortest.

Click on the link below to watch a video on how to install SPC.

Please check it out.
